• For maintaining process fluid temperatures and pumping viscous fluids
• High temperature to 350°F
• Accepts 2 standard 1/4” x 1” cartridge heaters & thermocouple.
• Pressure to 100 psig.
• Ceramic piston and liner in 316 SS cylinder case.
• Main flow 1/4” NPT female ports; Gland Ports 1/8” NPT female. -
Cylinder Casing Option
Stainless Steel
Operating Temperature Range
316 Stainless Steel: 0-177°C
Piston Size Max Dispense Volume Max Operating Pressure 1/4” Diameter 0.32 mL/rev 100 psig / 6.9 bar 3/8” Diameter 0.72 mL/rev 100 psig / 6.9 bar -
